Square Drop In Burner Pan Kit - Battery Ignition

18" Square Hybrid Drop In Burner Pan with Opening for Pilot Burner (20" OD); 6" Diameter Spiral Burner

• 43K BTU's (316 Stainless Steel) / 1/2 Gas Inlet with NG Orifice or LP Air Mixer

• 30VDC AWEIS Standard Capacity with a Field Serviceable Pilot Burner / Natural Gas or Liquid Propane
• Liquid Propane: Includes 120V Safety Backup Valve
• Includes 30VDC Power Supply
• (1) 18" Whisper Free Flex Gas Line 1/2".

• Note: Holds 29lbs of Fire Glass / 2 Bags of Lava Rock / 1 Bag of Rolled Lava Stone

24" Square Hybrid Drop In Burner Pan with Opening for Pilot Burner (26" OD); 12" Diameter Spiral Burner

• 85K BTU's (316 Stainless Steel) / 1/2 Gas Inlet with NG Orifice or LP Air Mixer

• 30VDC AWEIS Standard Capacity with a Field Serviceable Pilot Burner / Natural Gas or Liquid Propane
• Liquid Propane: Includes 120V Safety Backup Valve
• Includes 30VDC Power Supply
• (1) 18" Whisper Free Flex Gas Line 1/2".

• Note: Holds 52lbs of Fire Glass / 3 Bags of Lava Rock / 1 Bag of Rolled Lava Stone

30" Square Hybrid Drop In Burner Pan with Opening for Pilot Burner (32" OD); 18" Diameter Spiral Burner

• 162K BTU's (316 Stainless Steel) / 1/2 Gas Inlet with NG Orifice or LP Air Mixer

• 30VDC AWEIS Standard Capacity with a Field Serviceable Pilot Burner / Natural Gas or Liquid Propane
• Liquid Propane: Includes 120V Safety Backup Valve
• Includes 30VDC Power Supply
• (1) 18" Whisper Free Flex Gas Line 1/2".

• Note: Holds 81lbs of Fire Glass / 5 Bags of Lava Rock / 2 Bag of Rolled Lava Stone

36" Square Hybrid Drop In Burner Pan with Opening for Pilot Burner (38" OD); 24" Diameter Spiral Burner

• 170K BTU's (316 Stainless Steel) / 1/2 Gas Inlet with NG Orifice or LP Air Mixer

• 30VDC AWEIS Standard Capacity with a Field Serviceable Pilot Burner / Natural Gas or Liquid Propane
• Liquid Propane: Includes 120V Safety Backup Valve
• Includes 30VDC Power Supply
• (1) 24" Flex Line 3/4" With 1/2" x 3/4" Reducer.

• Note: Holds 117lbs of Fire Glass / 6 Bags of Lava Rock / 2 Bag of Rolled Lava Stone

48" Square Hybrid Drop In Burner Pan with Opening for Pilot Burner (50" OD); 36" Diameter Spiral Burner

• 238K BTU's (316 Stainless Steel) / 1/2 Gas Inlet with NG Orifice or LP Air Mixer

• 30VDC AWEIS Standard Capacity with a Field Serviceable Pilot Burner / Natural Gas or Liquid Propane
• Liquid Propane: Includes 120V Safety Backup Valve
• Includes 30VDC Power Supply
• (1) 36" Flex Line 3/4"

• Note: Holds 208lbs of Fire Glass / 11 Bags of Lava Rock / 2 Bag of Rolled Lava Stone

*** Burner Pan Note: Drop In Burner Pans have a depth of 2.5" and have a 1" Flange all the way around (unless specified as a different size by customer) to support itself inside the opening it is installed in. Opening Size should be no more than 1" larger than Pan Dimensions ***
